Electrocardiography is a fundamental part of cardiovascular assessment. It is an essential tool for investigating cardiac arrhythmias and is also useful in diagnosing cardiac disorders such as myocardial infarction.
Familiarity with the wide range of patterns seen in the electrocardiograms of normal subjects and an understanding of the effects of non-cardiac disorders on the trace are prerequisites to accurate interpretation.
The contraction and relaxation of cardiac muscle results from the depolarization and repolarization of myocardial cells.
These electrical changes are recorded via electrodes placed on the limbs and chest wall and are transcribed on to graph paper to produce an electrocardiogram (commonly known as an ECG).
The sinoatrial node acts as a natural pacemaker and initiates atrial depolarization. The impulse is propagated to the ventricles by the atrioventricular node and spreads in a coordinated fashion throughout the ventricles via the specialized conducting tissue of the His-Purkinje system.
Thus, after delay in the atrioventricular mode, atrial contraction is followed by rapid and coordinated contraction of the ventricles.
The electrocardiogram is recorded on to standard paper travelling at a rate of 25 mm/s. The paper is divided into large squares, each measuring 5 mm wide and equivalent to 0.2 s. Each large
